80-Gallon Electric Water Heater Replacement — Tampa, FL (August 2025)
For this Tampa, Florida project, we replaced an aging 80-gallon electric water heater that was delivering inconsistent hot water. After shutting off power at the breaker and verifying with a non-contact voltage tester, we isolated the cold water shutoff, drained the tank safely, and prepped the mechanical space for a clean, code-compliant installation.
Our scope covered removal and disposal of the old unit, installation of the new high-capacity electric tank, new TPR (temperature & pressure relief) valve, fresh dielectric unions, and flexible stainless-steel braided connectors. We inspected the anode rod access, confirmed thermostat settings (targeting 120°F), and verified bonding/grounding and wiring connections per manufacturer specifications and local building code.
Once the new water heater was in place, we purged air from the hot lines, performed a thorough leak check at every threaded and compression fitting, and verified recovery using an amp clamp on the elements. We also reviewed annual maintenance best practices: sediment flushing, TPR valve testing, and periodic visual inspection for corrosion or moisture around the pan and fittings.
Below are progress photos from the job. Each card includes a short description from a plumber’s perspective, highlighting the real-time troubleshooting, tools, and materials used during this water heater installation in Tampa.
Safe Shutdown & Drain Down
Power off at the breaker, verified with a non-contact voltage tester, then isolated the cold supply and attached a drain hose. Channel-lock pliers and an adjustable wrench helped disconnect the flexible connectors. This step prevents water damage and sets up a clean water heater replacement with proper drain-down and electrical lockout.
Removal & Site Prep
With the old tank removed for proper disposal, we checked clearances, platform integrity, and moisture with a meter. We staged dielectric unions, fresh PTFE tape, and pipe joint compound, and verified the pan and drain path. Good prep ensures a code-compliant electric water heater installation in Tampa, FL.
Piping & Electrical Connections
We set the new 80-gallon electric water heater, aligned hot/cold ports, and installed stainless braided supply lines to reduce stress on fittings. Using a torque wrench, we tightened to spec, added a new TPR valve, and made the electrical whip connections with UL-listed wire nuts. All work followed local building code and manufacturer guidelines.
Old Unit Ready for Disposal
Here’s the original 80-gallon electric water heater after removal. Years of service had led to reduced efficiency and sediment buildup inside the tank. Proper disposal ensures compliance with environmental regulations and clears the way for the new, energy-efficient model to be installed.
